Panasonic 6kW Deluxe Inverter Split Air Conditioner CS/CU-Z60XKR
Quantity:
Overview
Panasonic C6.0kW H7.2kW Deluxe Inverter Split Air Conditioner CS/CU-Z60XKR
Panasonic's new Deluxe series, the XKR Series combines slim design and the most cutting-edge technology.
Featuring:
- NanoeX
- Built-in WiFi
- Aerowings
- i-AutoX
Specifications
| MODEL INDOOR UNIT (240V / 1
OUTDOOR UNIT |
Phase / 50Hz) |
CS-Z60XKRW
[CU-Z60XKR] |
||
| Cooling / Heating ( | min-max) | kW | 6.00 [1.25-6.90]
6.50 [0.98-8.20] |
|
| Capacity ( | min-max) | Btu/h | 20,500 [4,260-23,500]
22,200 [3,340-28,000] |
|
| Air Flow | Indoor | L/s | 328/339 | |
| Dehumid | L/h | 3.3 | ||
| Running Current | A | 7.90/8.00 | ||
| Electrical Data Max Current | A |
11.6 |
||
| Power Input (min-max) | kW | 1.85 (0.35-2.20)
1.89 (0.26-2.64) |
||
| AEER / EER | W/W | 3.23/3.24 | ||
| ACOP / COP | W/W | 3.42/3.44 | ||
| Hot Climate | Cooling Heating | 3.5
3.5 |
||
| Star Rating Average Climate | Cooling Heating | 3.5
3.0 |
||
| Cold Climate | Cooling Heating | 3.5
2.0 |
||
| Hot Climate | TCSPF
HSPF |
5.40/6.19
5.41/5.45 |
||
| TCSPF & HSPF Average Climate | TCSPF
HSPF |
5.09/7.15
4.52/4.92 |
||
| TCSPF | 5.46/8.76 | |||
| Commercial
Cold Climate |
HSPF | 3.91/4.35 | ||
| Net Weight Indoor / Outdoor | 12/35 | |
| Dimensions | Indoor (HxWxD) | 295 x 1040 x 244
619 x 824 x 299 |
| Outdoor (HxWXD) | ||
| Refrigeration Pipe Diameter | Liquid Size | ø 6.35 (1/4)
ø 12.7 (1/2) |
| Gas Size | ||
| Pipe Extension Length | min-max (m) | 3~30 | |
| Maximum Elevation Length | m | 15 | |
| Pipe Length For Additional Gas | m | 10 | |
| Additional Gas Amount | g/m |
15 |
|
| Operating Range (Outdoor) | Cooling Heating | Degree °C | -10 ~ +46
-15 ~ +24 |
